CPH3403 MOSFET N-Channel 20V 2.2A SOT-23/SC-59 marking KC low on-resistance/Low Gate Threshold Voltage/high impedance/fast switch

Model：CPH3403
Mark / screen / code / typing：KC
Manufacturer：
Date Code：05+ 05+NOPB300
Package：SOT-23/SC-59
Standard Package：3000
Min Order：10

Hot selling goods

Product description

最大源漏极电压Vds Drain-Source Voltage	20V
最大栅源极电压Vgs(±) Gate-Source Voltage	12v
最大漏极电流Id Drain Current	2.2A
源漏极导通电阻ΩRds DΩ/Ohmain-SouΩ/Ohmce On-State Ω/Ohmesistance	0.15Ω/Ohm 1A,4V
开启电压Vgs（th） Gate-Source Threshold Voltage	0.4-1.3V
耗散功率Pd Power Dissipation	100mW/0.1W
Description & Applications	· Low ON resistance. · Ultrahigh-speed switching. · 2.5V drive.
描述与应用	·低导通电阻。 ·超高速开关。 ·2.5V驱动器
