Product description
类型
Type		低通 Low Pass
技术
Technology		RC
通道数
Number of Channels		2
中心/截止频率
Center / Cutoff Frequency		60MHz
衰减值
Attenuation Value		35dB@800MHz-2700MHz
电阻 - 通道 (Ω)
Resistance - Channel (Ohms)		68Ω
电流
Current
数值
Values		C=47pF
ESD 保护
ESD Protection		是 Yes
Description & ApplicationsFeatures • Two channels of EMI filtering • Pi-style EMI filters in a capacitor-resistor-capacitor (C-R-C) network • Greater than 40dB attenuation at 1GHz • +8kV ESD protection on each channel (IEC 61000-4-2 Level 4, contact discharge) • +15kV ESD protection on each channel (HBM) • Supports bipolar signals—ideal for audio applications • Chip Scale Package features extremely low lead inductance for optimum filter and ESD performance • 5-bump, 0.950mm X 1.410mm footprint Chip Scale Package (CSP) • Lead-free version available Applications • EMI filtering and ESD protection for headset microphone ports • Wireless Handsets • Handheld PCs / PDAs • MP3 Players • Digital Camcorders • Notebooks • Desktop PCs
描述与应用特点 •双通道EMI滤波 •丕式EMI滤波器的电容电阻电容 （C-R-C）网络 •大于40dB的衰减为1GHz •8 kV ESD保护每个通道 （IEC61000-4-2第4级，接触放电） •+15 kV的ESD（HBM）保护每个通道 •支持双极性信号的理想 音频应用 •芯片级封装，具有极低的 引线电感的最佳滤波器和ESD 性能 •5的磕碰，0.950毫米X1.410毫米的足迹 芯片级封装（CSP） •提供无铅版本 应用 •EMI滤波和ESD保护耳机 麦克风端口 •无线手机 •掌上电脑/掌上电脑 •MP3播放器 •数码摄像机 •笔记本电脑 •台式电脑
