Product description
类型
Type		低通 Low Pass
技术
Technology		RC
通道数
Number of Channels		4
中心/截止频率
Center / Cutoff Frequency		64MHz
衰减值
Attenuation Value		35dB@800MHz-2700MHz
电阻 - 通道 (Ω)
Resistance - Channel (Ohms)		100Ω
电流
Current
数值
Values		C=30pF
ESD 保护
ESD Protection		是 Yes
Description & ApplicationsFeatures • Six channels of EMI filtering for data ports • Pi-style EMI filters in a capacitor-resistor-capacitor (C-R-C) network • Greater than 32dB attenuation at 1GHz • +15kV ESD protection on each channel (IEC 61000-4-2 Level 4, contact discharge) • +30kV ESD protection on each channel (HBM) • Chip Scale Package features extremely low lead inductance for optimum filter and ESD performance • 15-bump, 2.960mm X 1.330mm footprint Chip Scale Package (CSP) • Lead-free version available Applications • EMI filtering and ESD protection for both data and I/O ports • Wireless Handsets • Handheld PCs / PDAs • MP3 Players • Notebooks • Desktop PCs
描述与应用特点 •6通道EMI过滤数据端口 •丕式EMI滤波器的电容电阻电容 （C-R-C）网络 •大于32分贝衰减为1GHz •+15 kV的ESD保护每个通道 （IEC61000-4-2第4级，接触放电） •+30 kV的ESD（HBM）保护每个通道 •芯片级封装，具有极低的 引线电感的最佳滤波器和ESD 性能 •15的磕碰，2.960毫米X1.330毫米足迹 芯片级封装（CSP） •提供无铅版本 应用 •EMI滤波和ESD保护为数据 和I / O端口 •无线手机 •掌上电脑/掌上电脑 •MP3播放器 •笔记本电脑 •台式电脑
