Product description
类型
Type		低通 Low Pass
技术
Technology		RC
通道数
Number of Channels		6
中心/截止频率
Center / Cutoff Frequency		120MHz
衰减值
Attenuation Value		30dB@1000MHz-3000MHz
电阻 - 通道 (Ω)
Resistance - Channel (Ohms)		100Ω
电流
Current
数值
Values		C=15pF
ESD 保护
ESD Protection		是 Yes
Description & ApplicationsFeatures • Six and eight channels of EMI filtering • +15kV ESD protection on each channel (IEC 61000-4-2 Level 4, contact discharge) • +30kV ESD protection on each channel (HBM) • Better than 30dB of attenuation at 1GHz to 3GHz • 15-bump, 2.960mm x 1.330mm footprint Chip Scale Package (CSPEMI606) • Chip Scale Package features extremely low lead inductance for optimum filter and ESD performance • 20-bump, 4.000mm x 1.458mm footprint Chip Scale Package (CSPEMI608) • Lead-free version available Applications • LCD data lines in clamshell wireless handsets • EMI filtering & ESD protection for high-speed I/O data ports • Wireless handsets / cell phones • Notebook computers • PDAs / Handheld PCs • EMI filtering for high-speed data lines
描述与应用特点 •6个和8个通道的EMI滤波 •+15 kV的ESD保护每个通道 （IEC61000-4-2第4级，接触放电） •+30 kV的ESD（HBM）保护每个通道 •优于30dB的衰减在1GHz至3GHz •15的磕碰，2.960毫米x1.330毫米足迹 芯片级封装（CSPEMI606） •芯片级封装，具有极低的 引线电感的最佳滤波器和ESD 性能 •20的磕碰，4.000毫米x1.458毫米足迹 芯片级封装（CSPEMI608） •提供无铅版本 应用 •液晶显示器数据线翻盖式无线手机 •EMI滤波与ESD保护的高速I/ O 数据端口 •无线手机/手机 •笔记本电脑 •掌上电脑/掌上电脑 •高速数据线路的EMI滤波
