FMQ1 Bias Resistor NPN+PNP 20V 50MA R1=R2=470Ω SOT153 MARKING Q1

Model：FMQ1
Mark / screen / code / typing：Q1
Manufacturer：
Date Code：05+
Package：SOT-153
Standard Package：3000
Min Order：10

Hot selling goods

Product description

Q1 Collector-Base Voltage(VCBO)	-60V
Q1Collector-Emitter Voltage(VCEO)	-50V
Q1Collector Current(IC) R1/R2	-0.15A
Q2 Collector-Base Voltage(VCBO)	60V
Q2 Collector-Emitter Voltage(VCEO)	50V
Q2 Collector Current(IC)	0.15A
Q1 Input Resistance(R1)	470Ω
Q1Base-Emitter Resistance(R2)	470Ω
Q1 Resistance Ratio	1
Q2 Input Resistance(R1)	470Ω
Q2Base-Emitter Resistance(R2)	470Ω
(R1/R2) Q2 Resistance Ratio	1
hFE DC Current Gain(hFE) Q1/Q2	120~560/120~560
fT Transtion Frequency(fT) Q1/Q2	140MHZ / 180MHZ
Pc Power Dissipation
Description & Applications

List of related models

Commodity Description	Supplier model	Manufacturer	Explain	Stock
FMQ2 NPN+PNP Complex Bipolar Digital Transistor 40V/-40V 30mA/-500mA 270/120 300mW/0.3W SOT-153/SMT5/SC-74A/SOT23-5 marking Q2 switching inverting interface driver circuit	FMQ2 Mark：Q2 Package：SOT-153/SMT5/SC-74A/SOT23-5	-	Batch number：05+ 05+	53000 Min Order:10
FMS1 PNP+PNP Complex Bipolar Transistor -60V -150mA HEF=120~560 SOT-153/SMT5/SC-74A marking S1 switch and digital circuit application	FMS1 Mark：S1 Package：SOT-153/SMT5/SC-74A	-	Batch number：05+ 05+	460 Min Order:10
FMS2 PNP+PNP Complex Bipolar Transistor -60V -150mA HEF=120~560 SOT-153/SMT5/SC-74A marking S2 switch and digital circuit application	FMS2 Mark：S2 Package：SOT-153/SMT5/SC-74A	-	Batch number：02+04PB9KM 05+	139500 Min Order:10
FMS2A PNP+PNP Complex Bipolar Transistor -60V -150mA HEF=120~560 SOT-153/SMT5/SC-74A marking S2 switch and digital circuit application	FMS2A Mark：S2 Package：SOT-153/SMT5/SC-74A	-	Batch number：05+	5 Min Order:10
FMS3 PNP+PNP Complex Bipolar Transistor -120V -50mA HEF=180~820 SOT-153/SMT5/SC-74A marking S3 switch and digital circuit application	FMS3 Mark：S3 Package：SOT-153/SMT5/SC-74A	-	Batch number：05+ 03+	2700 Min Order:10
FMW1 NPN+NPN Complex Bipolar Transistor 60V 150mA HEF=120~560 SOT-153/SMT5/SC-74A marking W1 switch and digital circuit application	FMW1 Mark：W1 Package：SOT-153/SMT5/SC-74A	-	Batch number：05+ 04+NOPB1300	23500 Min Order:10
FMW2 NPN+NPN Complex Bipolar Transistor 60V 150mA 120~560 SOT-153/SMT5/SC-74A marking W2 switch and digital circuit application	FMW2 Mark：W2 Package：SOT-153/SMT5/SC-74A	-	Batch number：05+ 05+	0 Min Order:10
