MM1385BNRE LDO Voltage Regulator 4.5V 100mV/0.1V SOT-153/SOT-25A/SOT23-5 marking DBK Short-Circuit Protection Over-Temperature Protection

Hot selling goods

Product description
电路数量
Number of Regulators
1
输入电压VIN
Voltage - Input
1.8~12V
输出电压VOUT
Voltage - Output
4.5V
输出电流Io
Current - Output
50mA
最大压降VDO
Voltage - Dropout
100mV/0.1V
带使能脚EN/CE(ON/OFF功能)
With Enable Pin
无 No
最大耗散功率Pd
Power dissipation
150mW/0.15W
Description & ApplicationsMicrominiature Low-Power Consumption Low-Saturation Regulator ;• No-load input current 95µA typ. •I/O voltage difference 0.1V typ.(Io=50mA) • Ripple rejection ratio 70dB typ. •Output current 150mA max. •Output noise voltage 35µVrms typ. •Output on/off control High ON, Low OFF
描述与应用超小型低功耗低饱和稳压器;•无负载输入电流95μA(典型值) •I / O电压差0.1V(典型值)(IO=50毫安) 纹波抑制比70dB的典型 •输出电流最大150mA。 •输出噪声电压典型35μVrms •输出开/关控制高开,关低
