XC62EP1902MR LDO Voltage Regulator 1.9V 100mV/0.1V With Enable Pin SOT-153/SOT-25/SOT23-5 marking 191 Short-Circuit Protection Over-Temperature Protection

Hot selling goods

Product description
电路数量
Number of Regulators
1
输入电压VIN
Voltage - Input
12V
输出电压VOUT
Voltage - Output
1.9V
输出电流Io
Current - Output
100mA/0.1A
最大压降VDO
Voltage - Dropout
100mV/0.1V
带使能脚EN/CE(ON/OFF功能)
With Enable Pin
有 Yes
最大耗散功率Pd
Power dissipation
150mW/0.15W
Description & Applications•Boosting Voltage Regulators •Dropout Voltage : 0.1A@100mA (Performance depends on the external transistor characteristics.) •Maximum Output Current : 1000mA •Output Voltage Range :1.5V~6.0V in 100mV increments •Highly Accurate : Setting voltage ±2% •Low Power Consumption : 50μA (VOUT=5.0V) (TYP.) : 0.2μA (Stand-by) (TYP.) •Output Voltage Temperature Characteristics : ±100ppm/ ℃ (TYP.) •Line Regulation : 0.1%/V (TYP.) •CMOS Low Power Consumption
描述与应用•升压稳压器 •漏失电压:0.1A@100MA (性能取决于外部晶体管的特性)。 •最大输出电流:1000mA •输出电压范围:1.5V〜6.0V在100mV增量 •高精度:±2%电压设置 •低功耗:50μA(VOUT=5.0V)(典型值)  :0.2μA(备用)(典型值) •输出电压的温度特性  温度系数±100ppm/℃(典型值) 线路调整:0.1%/ V(典型值) •CMOS低功耗
