RP150K008A LDO Voltage Regulator 1.5~3.3V With Enable Pin PLP2020-8 marking R08 Short-Circuit Protection Over-Temperature Protection

Hot selling goods

Product description
电路数量
Number of Regulators
2
输入电压VIN
Voltage - Input
6V
输出电压VOUT
Voltage - Output
1.5~3.3V
输出电流Io
Current - Output
300mA/0.3A
最大压降VDO
Voltage - Dropout
带使能脚EN/CE(ON/OFF功能)
With Enable Pin
有 Yes
最大耗散功率Pd
Power dissipation
Description & ApplicationsLOW NOISE Dual 300mA LDO •Supply Current Typ. 24µA×2 (VR1&VR2) • Standby Current Typ. 0.1µA • Dropout Voltage Typ. 0.21V (IOUT=300mA, VOUT=2.8V) Typ. 0.24V (IOUT=300mA, VOUT=2.5V) • Ripple Rejection Typ. 80dB (f=1kHz) • Temperature-Drift Coefficient of Output Voltage Typ. ±30ppm/°C • Line Regulation Typ. 0.02%/V • Output Voltage Accuracy ±1.0% • Input Voltage Range 2.5V to 5.25V • Output Voltage Range. 1.5V to 3.3V • Built-in Fold Back Protection Circuit .Typ. 50mA • Built-in Auto Discharge Function B Version • Ceramic capacitors are recommended to be used with this IC CIN=COUT=1.0µF or more • Power source for portable communication equipment. • Power source for electrical appliances such as cameras, VCRs and camcorders. • Power source for battery-powered equipment.
描述与应用低噪声双300毫安LDO;•供电电流典型。 24μA×2(VR1和VR2) •待机电流典型。 0.1μA •漏失电压典型值。 0.21V(IOUT=的300mA,VOUT=2.8V) 典型。 0.24V(IOUT=的300mA,VOUT= 2.5V) •纹波抑制典型。 80分贝(F =1kHz时) •典型输出电压的温度漂移系数。 ±30PPM/°C •线路调整典型。 0.02%/ V •输出电压精度±1.0% •输入电压范围2.5V至5.25V •输出电压范围。 1.5V至3.3V •内置折返保护电路的典型值。 50毫安 •内置自动放电功能B版本 •陶瓷电容器建议使用此IC CIN= COUT=1.0μF以上 •便携式通信设备的电源。 •电源的电器,如摄像机,录像机和摄像机。 •电池供电设备的电源。
