Product description
类型
Type		低通 Low Pass
技术
Technology		RC
通道数
Number of Channels		6
中心/截止频率
Center / Cutoff Frequency		200MHz
衰减值
Attenuation Value		20dB@1000MHz-3000MHz
电阻 - 通道 (Ω)
Resistance - Channel (Ohms)		100Ω
电流
Current
数值
Values		C=8.5pF
ESD 保护
ESD Protection		是 Yes
Description & ApplicationsFeatures • Four, six and eight channels of EMI filtering with integrated ESD protection • Pi-style EMI filters in a capacitor-resistorcapacitor (C-R-C) network • ±15kV ESD protection on each channel (IEC 61000-4-2 Level 4, contact discharge) • ±30kV ESD protection on each channel (HBM) • Greater than 20dB attenuation (typical) at 1 GHz • TDFN package with 0.40mm lead pitch: • 4-ch. = 8-lead TDFN • 6-ch. = 12-lead TDFN • 8-ch. = 16-lead TDFN • Tiny TDFN package size: • 8-lead: 1.7mm x 1.35mm • 12-lead: 2.5mm x 1.35mm • 16-lead: 3.3mm x 1.35mm • Increased robustness against vertical impacts during manufacturing process • Lead-free version available Applications • LCD and Camera data lines in mobile handsets • I/O port protection for mobile handsets, notebook computers, PDAs etc. • EMI filtering for data ports in cell phones, PDAs or notebook computers. • Wireless handsets • Handheld PCs/PDAs • LCD and camera modules
描述与应用特点 •四，六，八频道的EMI滤波 集成ESD保护 •PI式EMI滤波器一个电容resistorcapacitor的（CRC）网络 •±15kV的ESD保护每个通道 （IEC61000-4-2第4级，接触放电） •±30kV的ESD（HBM）保护每个通道 •大于20dB衰减（典型值）在1 GHz的 •与0.40mm引脚间距的TDFN封装： •4通道。 = 8引脚TDFN封装 •6声道。 =12引脚TDFN •8路。 =16引脚TDFN •微型TDFN封装大小： •8引线：1.7所述1.35毫米 •12，铅：2.5×1.35毫米 •16，铅：3.3毫米所述1.35毫米 •立式影响的提高了稳定性，对 在生产过程中 •提供无铅版本 应用 •LCD和相机数据线在手机 •I / O端口保护手机，笔记本 电脑，PDA等 •EMI过滤数据端口在手机，PDA 或笔记本电脑。 •无线手机 •掌上电脑/掌上电脑 •液晶显示屏和摄像头模块
