darlington transistor BSP52T1 NPN 1A 80V SOT-223 markignR20 switch power amplifier
| 集电极-基极反向击穿电压V(BR)CBO Collector-Base Voltage(VCBO) | 90V |
| 集电极-发射极反向击穿电压V(BR)CEO Collector-EmitterVoltage(VCEO) | 80V |
| 集电极连续输出电流IC Collector Current(IC) | 1A |
| 截止频率fT Transtion Frequency(fT) | |
| 直流电流增益hFE DC Current Gain(hFE) | 2000 @ 10V,0.5A |
| 管压降VCE（sat） Collector-Emitter SaturationVoltage | 1.3V |
| 耗散功率Pc Power Dissipation | 800mW/0.8W |
| Description & Applications | • This NPN small signal Darlington transistor is designed for use in switching applications, such as print hammer, relay, solenoid and lamp drivers. • The device is housed in the SOT-223 package, which is designed for medium power surface mount applications，The SOT-223 Package can be soldered using wave or reflow. The formed leads absorb thermal stress during soldering, eliminating the possibility of damage to the die。 • Use BSP52T1 to order the 7 inch/1000 unit reel • Pb−Free Packages are Available • PNP Complement is BSP62T1 • Available in 12 mm Tape and Reel |
| 描述与应用 | •这NPN小信号达林顿晶体管被用在开关应用，如打印电锤，继电器，电磁阀和灯驱动器设计。 •该器件采用SOT-223封装，这是专为中等功率表面贴装应用，SOT-223封装，可以使用波或回流焊接。所形成的线索在焊接热应力吸收，消除模具损坏的可能性。 •使用BSP52T1到责令7 inch/1000的单位卷轴 •无铅包可用 •PNP补BSP62T1 •可在12毫米编带和卷轴 |
