2SC4726 NPN Transistors(BJT) 20V 50mA 3.2GHz 56~120 <500mV/0.5V SOT-523/SC75A/EMT3 marking AND high frequency amplifier

Hot selling goods

Product description
集电极-基极反向击穿电压V(BR)CBO
Collector-Base Voltage(VCBO)
20V
集电极-发射极反向击穿电压V(BR)CEO
Collector-Emitter Voltage(VCEO)
11V
集电极连续输出电流IC
Collector Current(IC)
50mA
截止频率fT
Transtion Frequency(fT)
3.2GHz
直流电流增益hFE
DC Current Gain(hFE)
56~120
管压降VCE(sat)
Collector-Emitter Saturation Voltage
<500mV/0.5V
耗散功率Pc
Power Dissipation
150mW/0.15W
Description & Applications Features •High-Frequency Amplifier Transistor (11V, 50mA, 3.2GHz) •High transition frequency. (Typ. fT= 3.2GHz) •Small rbb’⋅Cc and high gain. (Typ. 4ps) •Small NF.
描述与应用 特点 •高频晶体管放大器(11V,50mA时3.2GHz的) •高转换频率。 (典型值英尺=3.2GHz的) •小RBB'⋅CC和高增益。 (典型值4PS) •小NF。
