TPSMA30-4/5AT TVS/ESD 24.3V 9.2A DO-214AC/SMA-30v marking BQP

Hot selling goods

Product description
极性
Polarization
单向 Unidirectional
反向关断电压/工作电压VRWM
Reverse Standoff Voltage
24.3V
反向击穿电压VBR
Breakdown Voltage
30V
峰值脉冲耗散功率PPPM
Peak Pulse Power Dissipation
400W
峰值脉冲电流IPPm
Peak Forward Surge Current
9.2A
额定耗散功率Pd
Power dissipation
Description & ApplicationsSurface Mount Automotive Transient Voltage Suppressors;Specification Features: • Vishay Semiconductors formerly General Semiconductor • Surface Mount Automotive Transient Voltage Suppressors • Plastic package has Underwriters Laboratory Flammability Classification 94V-0 • Ideal for automated placement • Low profile package • Built-in strain relief • Exclusive patented PAR®oxide passivated chip construction • 400W peak pulse power capability with a 10/1000ms waveform, repetition rate (duty cycle): 0.01% • Excellent clamping capability • Low incremental surge resistance • Very fast response time • For devices with V(BR) ≥ 10V ID are typically less than 1.0mA at TA = 150°C • Designed for under the hood surface mount applications • High temperature soldering:250°C/10 seconds at terminals
描述与应用表面贴装汽车 瞬态电压抑制器;规格特点: •威世半导体原通用半导体 •表面贴装汽车瞬态电压抑制器 •塑料包装有保险商实验室可燃性分类94V-0 •适合自动放置 •薄型包装 •内置应变救灾 •独家专利的PAR®氧化物钝化建设的 •400W峰值脉冲功率能力与一个的10/1000ms波形,重复率(占空比):0.01% •出色的钳位能力 •低增量浪涌电阻 •非常快的响应时间 •设备V(BR)≥10V ID通常小于1.0mA在TA= 150°C •专为引擎盖下的表面贴装 应用程序 •高温焊接:250°C/10秒钟码头
